SM090-4VM Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning

Name: SM0904VM Refrigeration Scroll Compressor 75HP SM090S4VC For Air Conditioning
Brand: Danfoss
Price: 1 USD

Type : refrigeration compressor

Net weight : 65KG

Voltage : 380/3/60

Color : Blue

Horse power : 7.5HP

Segment usage : Air conditioning

Apllication : refrigeration

Product name : Scroll compressor

warranty : 1 year

Refrigerant : R22

Brand Name : Danfoss

Certification : CE UL

Place of Origin : China

MOQ : 1PCS

Price : discussed

Supply Ability : 500PCS

Delivery Time : 1-5 Days

Packaging Details : wooden packaging

Payment Terms : T/T,Western Union

Model Number : SM090S4VC(SM090-4VM)

Contact Now

SM090-4VM Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning

Product Overview

The SM090-9VM is a high-performance scroll compressor designed for air conditioning applications, featuring 7.5HP capacity and robust construction for reliable operation.

Gross Weight	70.53 kg
Net Weight	65 kg
EAN	5702424053406

Certifications & Standards

Approval Standard CE, UL

Brand Technique Scroll Compressor

IP Protection Class IP54 (with cable gland)

Technical Specifications

Compressor Power Supply 380/3/60 V/Ph/Hz

Nominal Cooling Capacity 90.1 kBtu/h (26.4 kW)

Capacity Control Fixed Speed

Refrigerant R22

RLA 15.7 A

LRA 113 A

Rotational Speed at 60Hz 3500 rpm

Swept Volume 120.5 cm³

Oil Charge 3.25 L

Oil Type Mineral (160P)

Physical Dimensions & Connections

Total Height 508 mm

Diameter 254 mm

Suction Connection 1 1/8 in

Discharge Connection 3/4 in

Connection Type Brazed

Operating Parameters

High Side Max Pressure 30.2 bar

Low Side Max Pressure 25 bar

High Side Temperature Range -35°C to 150°C

Low Side Temperature Range -35°C to 63°C

Maximum Starts per Hour 12

Included Components

Shipped Instructions Installation Instructions

Shipped Mounting Mounting Kit with Grommets, Bolts, Nuts, Sleeves and Washers

Shipped Oil Initial Oil Charge

Product Images

SM090-4VM Refrigeration Scroll Compressor 7.5HP SM090S4VC For Air Conditioning
